MC28 Comacchio: robust drill for demanding civil works
MC28 Comacchio: robust drill for demanding civil works

MC 28 Drill rig

Tous les produits

The MC 28 is powered by a 205 kW engine and built on a solid, robust structure. It features a 14-ton traction mast and reinforced clamps.

This rig is suitable for all types of civil engineering operations including micropiles, anchors, jet grouting, drainage, soil nailing, and general reinforcement.

Regarding weight, the MC 28 ranges from approximately 21,000 to 24,000 kg, making it a stable and heavy-duty machine for tough terrain.

Want more information about the MC 28? Contact us!

Caractéristiques techniques
  1. Puissance moteur : 205 kW
  2. Feed stroke : 7 200 - 10 200 mm
  3. Poussée : 14 000 daN
  4. Traction : 14 000 daN
  5. Torque : 610 - 4 800 daNm
  6. Clamp range : 45 - 520 mm
  7. Weight : 21 000 - 24 000 kg
  8. Speed min. / max. : 20 - 210 rpm
Retrouvez toutes vos pièces et outils de forage sur maforeuse.com
